Vibrating Screen

HJ series vibrating screen is a new type of circular vibrating screen product which is improved on the basis of YA and YK series, comprehensive customer site use and maintenance experience......

Scope of application:
mineral processing, electric power, chemical industry, building materials

Chat Now Send E-mail

Share With:

Product Description

Feature Table Parameters Service Support

Product Description

HJ series vibrating screen is a new type of circular vibrating screen product which is improved on the basis of YA and YK series, comprehensive customer site use and maintenance experience, and upgraded for heavy duty conditions.

Applied material : HJ series vibrating screen can process more than 200 kinds of materials, such as quartz stone, river pebbles, calcite, dolomite, granite, basalt, iron ore, limestone, diabase, etc.

Feature

● 1. Strong exciting force, high screening efficiency, big capacity;

● 2. Reliable structure, long service life, small noise, low electricity consumption;

● 3. Long flowing line and various screening grades;

● 4. Simple structure, convenient in operation and maintenance.

Table Parameters

Model	Motor Power (kw)	Vibrating Frequency (r/min)	Max.Feeding Size (mm)	Production (t/h)	Dimensions （L×W×H）(mm)
2HX1545	15	780-900	200	60-500	5380×2295×1410
3HX1545	15	780-900	200	65-500	5575×2295×1990
4HX1545	18.5	780-900	200	65-500	5765×2295×1990
2HX1855	18.5	780-900	200	75-600	5680×2565×1450
3HX1855	22	780-900	200	75-600	5900×2565×2110
4HX1855	22	780-900	200	75-600	6030×2565×2500
2HX2165	30	780-900	200	85-700	7160×2990×1690
3HX2165	30	780-900	200	85-700	7380×2990×2365
4HX2165	37	780-900	200	85-700	7430×2990×2550
2HX2465	37	780-900	200	100-800	7160×3290×1690
3HX2465	37	780-900	200	100-800	7380×3290×2365
4HX2465	37	780-900	200	100-800	7430×3290×2500
2HX2765	37	780-900	200	120-900	7180×3570×1805
3HX2765	45	780-900	200	120-900	7390×3570×2445
4HX2765	45	780-900	200	120-900	7480×3570×2715
2HX3065	37	780-900	200	200-1200	7180×3870×1805
3HX3065	45	780-900	200	200-1200	7390×3870×2445
4HX3065	45	780-900	200	200-1200	7480×3870×2715
2HX3075	22×2	780-900	400	200-1300	8700×4055×1980
3HX3075	37×2	780-900	400	200-1300	8940×4120×2720
