Vibrating Feeder

Hongji grizzly feeders are vibrating feeders suitable to feed any primary crusher. They are a perfect match with the primary crushers, jaw crushers, impact crushers and cone crusher so on.

Scope of application:

river pebbles, limestone, dolomite, granite, coal, diabase, basalt, construction waste, etc.

Chat Now Send E-mail

Share With:

Product Description

Feature Table Parameters Service Support

Product Description

Hongji grizzly feeders are vibrating feeders suitable to feed any primary crusher. They are a perfect match with the primary crushers, jaw crushers, impact crushers and cone crusher so on. They have been designed for heavy duty operation and are also suitable for mining applications.

Applied material : Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.

Feature

● 1. Steady vibration, continuous and even feeding;

● 2. Pre-screening fine materials when feeding, so as to increase crushing efficiency;

● 3. Low noise and power consumption;

● 4. High working efficiency, large feeding capacity.

Table Parameters

Model	Max. Feeding Size (mm)	Processing Capacity (t/h)	Motor Power (kw)	Dimensions (L×W×H)(mm)
GZD-650×2300	300	80-100	1.2×2	2300×1360×780
GZD-750×2500	350	100-130	1.5×2	2500×1460×780
GZD-850×3000	400	120-150	3×2	3110×1800×1600
GZD-1000×3600	500	150-200	3.7×2	3850×1950×1630
GZD-1100×3600	580	240-300	3.7×2	3600×2050×1660
GZD-1300×3600	650	450-600	7.5×2	3900×2350×1750
GZD-1500×3600	1050	450-1000	7.5×2	3900×2000×1750
GZD-2000×3600	1200	550-1000	10×2	3600×2000×1750
GZD-2500×5000	1500	650-1500	18×2	5000×2500×1800
ZSW-380×95	500	100-180	11	3920×1640×1320
ZSW-490×110	630	150-400	15	4980×1830×1320
ZSW-490×130	750	400-700	22	4980×2580×2083
ZSW-600×130	750	400-700	22	6082×2580×2083
ZSW-600×150	800	500-900	30	6086×2662×1912
ZSW-600×180	900	700-1300	45	6310×3262×2230
ZSW-600×200	1200	800-1500	55	6310×3462×2230
