Roller Crusher

Roll crushers are used for both, primary and secondary crushing stage. They guarantee a strictly defined final grain size with a minimum of fine grains, and to crusher coke, sinter, coal, soft to medium-hard rock, ore......

Scope of application:
Sorting plants of mines, coal mines, cement plants, chemical plants, smelting plants, coal-fuel power plants.

Chat Now Send E-mail

Share With:

Product Description

Feature Table Parameters Service Support

Product Description

The Double Roller Crusher, also known as roll crusher, toothed roll crusher, is suitable for fine crushing the medium hardness rock with compressive strength ≤160MPa, such as ore, rock, coke, coal, clinker, ceramic raw materials, slag, refractory materials, and chemical materials.

According to the number of rolls, the roll crushers can be divided into single roll crushers, double roll crushers, and four roll crushers. A double roll crusher is the most used type. We produce industrial roller crushers and the laboratory uses a small roll crusher.

Applied material : Coal, ash, coke, fertilizer, potash, rock salts, lime, gypsum rocks and so on.

Feature

● 1. Used for almost any material and for crushing up to 0.5 mm.

● 2. More economical because of its higher production capacity and lower power requirement.

● 3. Segmented roll designs available in a wide selection of tooth configurations and abrasion-resistant materials for rugged performance and long life.

● 4. To accommodate a variety of crushing applications, the crusher achieves reduction ratios up to 16:1.

● 5. Compared to impact crushing, roller crusher creates much less dust resulting in a cleaner work area.

● 6. Simplified two-motor drive system eliminates gearbox maintenance.

Table Parameters

Model	Roller diameter (mm)	Roller width (mm)	Input Size (mm)	Discharging Gate (mm)	Processing capacity (t/h)	Power Models	Motor power (kw)
2PG0425	Ф400	250	≤25	2-8	5-10	Y132M-6	5.5×2
2PG0640	Ф600	400	≤25	2-8	10-20	Y180L-6	15×2
2PG0740	Ф700	400	≤25	2-8	15-30	Y200L-4	30×2
2PG0850	Ф800	500	≤25	2-8	20-40	Y225M-4	45×2
2PG1060	Ф1000	600	≤30	2-10	30-50	Y250M-4	55×2
2PG1260	Ф1200	600	≤30	2-10	40-70	Y315M-6	75×2
2PG1560	Ф1500	600	≤30	2-10	60-110	Y315L-6	110×2
